规 格

比重

进出口径

mm

马力

50Hz

60Hz

重量

kg

相数

HP

极数

曲线

全扬程

M

全流量

L/min

曲线

全扬程

M

全流量

L/min

TD-40SK-1

1.1

50X40

3ø

1

2

a

14

280

A

13

250

29

TD-40SK-2

1.1

50X40

3ø

2

2

b

18

400

B

22

320

38

TD-40SK-3

1.1

50X40

3ø

3

2

c

20

420

C

26

420

41

TD-50SK-3

1.1

65X50

3ø

3

2

d

21

530

D

23

520

41

TD/STD-50SK-5

1.1

65X50

3ø

5

2

e

31

580

E

36

560

55

TD/STD-65SK-5

1.1

80X65

3ø

5

2

f

29

550

F

29

700

55

TD/STD-65SK-7.5

1.1

80X65

3ø

7.5

2

g

34

730

G

37

960

95

TD/STD-65SK-10

1.1

80X65

3ø

10

2

h

37

760

H

39.5

1100

106

TD-40SP-3

1.4

50X40

3ø

3

2

i

22

400

I

23

340

41

TD-50SP-3

1.4

65X50

3ø

3

2

j

19

500

J

19

400

41

TD/STD-50SP-5

1.4

65X50

3ø

5

2

k

28

560

K

32

500

55

TD/STD-65SP-5

1.4

80X65

3ø

5

2

l

27

520

L

25

600

55

TD/STD-65SP-7.5

1.4

80X65

3ø

7.5

2

m

31

720

M

35

750

95

TD/STD-65SP-10

1.4

80X65

3ø

10

2

s

33

750

S

38

850

106

TD-50SL-1

1.4

50X50

3ø

1

4

q

6

320

Q

8.5

400

30

TD-80SL-2

1.4

80X80

3ø

2

4

r

9

400

R

13

480

40

TD-80SK-5

1.1

80X80

3ø

5

2

u

24

860

黄色部份为大流量规格

TD-80SK-7.5

1.1

80X80

3ø

7.5

2

t

26

1100

TD-80SK-10

1.1

80X80

3ø

10

2

w

30

1100

TD-100SK-10

1.1

100x100

3ø

10

2

o

25

1235

O

31

1200

102

TD-100SK-15

1.1

100x100

3ø

15

2

p

35

1710

P

35

1950

114

TD-125SK-15

125X125

15

2
